For Generator RLC Load Bank With Intelligent Control Vertical Outline Cooling

Brand Name : KAIXIANG

Model Number : 600 KW

Certification : ISO9001

Place of Origin : HEBEI CHINA

MOQ : ONE SET

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20 SETS ONE MONTH

Delivery Time : ONE MONTH AFTER GET DEPOSIT

Packaging Details : WOODEN CASE

Resistive load : 600 KW

Display Precision : 0.5 class

Load Step : 4 steps, Resistive load: 100kW, 100kW, 200kW, 200kW min load step: 100 kW

Rating Voltage/Frequency : 600 Kw at 6.6kVAC, 3 phase 4 wire, 50 Hz

Insulation : F

weight : 1200 kg

Contact Now

For Generator RLC Load Bank With Intelligent Control Vertical Outline Cooling

Product Description

1. This system, which is of independent research and development of electricity load test equipment by our technology, combining dry load module with the automatic measurement and control module, can accurately detect all kinds of generator output power and load capacity, full load and overload test.

2. The system can be used with a computer to realize the intelligent control, automatically completing the special test to all electrical parameters of generating set and generating tables, graphs, and supporting the print, comprehensively from the cumbersome manual operation to provide scientific and efficient detection means for the power generating sets.

Technical Parameter

Rating Voltage/Frequency	600Kw at 6.6kVAC, 3 phase 4 wire, 50 Hz
Max Load Power	Resistive load:600kW
Load Steps	4 steps, Resistive load: 100kW, 100kW, 200kW, 200kW min load step: 100 kW
PF(Power Factor)	1
Load Accuracy (each step)	±5%
Load Accuracy (overall)	3%
Display Precision	0.5 grade
Control Power	380VAC 50Hz 3 phase 4 wire, phase voltage 220VAC, 50Hz
Wire Connection	Load power supply input——star coupling Control power supply input——terminal block
Insulation	F
Max Protection Grade	IP21
Way of Working	Continuous Work
Cooling	Fan forced cooling, horizontal inlet air and vertical outlet cooling

Product Advantages

1. Power consumption components: made by special alloy resistance, high temperature resisting, high heat dissipation capability, high heat stability, no naked light, safety and reliability. Running temperature is 1/3 of rating.

2. Weather-proof structure: containerized structure provides ultra protection, protection grade higher than IP55.

3. Material and coating: the body adopt cold-rolled steel plate that processed by galvanizing corrosion protection, powder coated and spray paint.

Application

Load Banks are used with Engine Generators, Battery Systems, UPS Systems, Inverters, Ground Power Units, Auxiliary Power Units, Aircraft Power Generators, Wind Generators, and Hydro Generators.
